Phosphor Bronze (C51000)

Composition: Copper-Tin-Phosphorus alloy

Key Properties: Excellent spring properties, high fatigue resistance, superior corrosion resistance

Applications: High-vibration environments, coastal installations, heavy-duty tap connectors

Conductivity: 15% IACS (International Annealed Copper Standard)

Silicon Bronze (C65500)

Composition: Copper-Silicon-Zinc alloy

Key Properties: High strength, excellent corrosion resistance, good electrical conductivity

Applications: Marine environments, industrial areas, general utility applications

Conductivity: 20% IACS

Aluminum Bronze (C95400)

Composition: Copper-Aluminum-Iron-Nickel alloy

Key Properties: Exceptional strength, superior wear resistance, outstanding corrosion resistance

Applications: Heavy-load applications, harsh environmental conditions, high-current connections

Conductivity: 13% IACS

Tin Bronze (C90700)

Composition: Copper-Tin alloy (traditional bronze)

Key Properties: Good machinability, reliable casting properties, moderate conductivity

Applications: Standard duty connectors, general electrical distribution

Conductivity: 14% IACS

Manganese Bronze (C86300)

Composition: Copper-Zinc-Manganese-Iron-Aluminum alloy

Key Properties: High tensile strength, excellent wear resistance, good machinability

Applications: Heavy-duty mechanical connections, high-stress installations

Conductivity: 17% IACS

Custom Bronze Alloys

Composition: Tailored to customer specifications

Key Properties: Application-specific performance characteristics

Applications: Specialized electrical utility requirements, unique environmental conditions

Note: We can develop custom bronze alloys to meet specific customer requirements

Range-Taking Design

Each bronze wedge connector accommodates multiple conductor sizes, reducing the number of SKUs required for utility operations and simplifying field inventory management.

Superior Corrosion Resistance

Bronze casting alloys provide exceptional resistance to atmospheric corrosion, salt spray, industrial pollutants, and galvanic corrosion, ensuring decades of reliable service life.

Shear Bolt Installation

Integrated shear bolt design ensures proper installation torque is achieved every time, eliminating guesswork and ensuring consistent, reliable electrical connections.

Two-Piece Capture Design

The innovative design captures the tap conductor interface, preventing component drops during installation and enabling single-person installation from bucket trucks.

Dual Hex Head System

Primary shear head with secondary hex allows for field adjustments if needed, while the rivet-retained shear head prevents falling debris hazards.

RUS Approved

All bronze tap connectors meet Russian Utility Standards (RUS) requirements, ensuring global acceptance and compliance.

A: Bronze electrical connectors offer significantly superior corrosion resistance compared to aluminum, particularly in coastal, industrial, and high-humidity environments. Bronze also provides better resistance to galvanic corrosion when connecting dissimilar metals. The mechanical strength of bronze casting alloys ensures longer service life and reduced maintenance requirements. While initial cost is higher, the lifecycle cost advantage of bronze connectors makes them the preferred choice for critical installations and harsh environments.

A: Yes, our bronze tap connectors are suitable for both aluminum and copper conductors. Bronze is metallurgically compatible with copper, eliminating galvanic corrosion concerns. The connector specifications table indicates which models accommodate copper (CU) tap conductors. Bronze’s excellent compatibility with copper makes these connectors ideal for mixed-metal installations common in utility networks.

A: Both sand casting and permanent mold casting methods produce high-quality bronze connectors, but each has distinct advantages. Permanent mold casting delivers superior surface finish, tighter tolerances, and enhanced mechanical properties, making it ideal for high-volume standardized products. Sand casting offers greater flexibility for complex geometries and custom sizes while maintaining excellent quality. We select the optimal casting method based on connector size, production volume, and specific application requirements.

A: Bronze alloy selection depends on several factors: environmental conditions (coastal, industrial, rural), current load requirements, mechanical stress levels, temperature extremes, and budget. For marine environments, we recommend silicon bronze or aluminum bronze for maximum corrosion resistance. For high-vibration applications, phosphor bronze offers superior fatigue resistance. Our technical team provides free consultation to recommend the optimal bronze casting alloy for your specific utility application.

A: Properly installed bronze bolted wedge connectors typically provide 30-50+ years of maintenance-free service, significantly outlasting aluminum alternatives. The actual service life depends on environmental conditions, current load, and installation quality. Bronze’s inherent corrosion resistance and mechanical stability ensure reliable long-term performance even in challenging conditions. Regular visual inspections are recommended, but mechanical or electrical maintenance is rarely required.

A: Yes, our bronze electrical connectors are manufactured to meet or exceed multiple international standards including IEEE, ANSI, IEC, and RUS (Russian Utility Standards). We maintain comprehensive quality documentation and can provide material test certificates, dimensional inspection reports, and compliance certifications. All products undergo rigorous testing for electrical conductivity, mechanical strength, and corrosion resistance.

A: Absolutely. Our in-house bronze casting foundry capabilities enable us to design and manufacture custom bronze connectors to meet unique specifications. We can modify existing designs, develop entirely new connector configurations, or formulate custom bronze alloys. Our engineering team collaborates with customers from initial concept through prototype development to full production. Minimum order quantities for custom connectors vary based on complexity.

A: Installation is straightforward: (1) Position the connector on the run conductor, (2) Insert the tap conductor through the connector body, (3) Using a standard wrench or impact driver, tighten the shear bolt until it shears off at the predetermined torque. The shear bolt design eliminates the need for torque wrenches and ensures proper installation force every time. The two-piece capture design prevents component drops during installation, enabling safe single-person installation from bucket trucks or platforms.

A: We maintain strategic inventory and utilize efficient international logistics to minimize delivery times. Standard sea freight to USA ports typically takes 25-35 days from order confirmation. We offer expedited air freight for urgent orders (7-10 days transit). For regular customers, we can establish consignment inventory programs within the USA to ensure immediate product availability. Our export documentation team ensures smooth customs clearance and provides comprehensive tracking throughout the shipping process.

 In-House Foundry

Complete control over the entire bronze casting process ensures consistent quality, rapid prototyping capabilities, and flexibility to meet custom requirements. Our foundry utilizes modern casting equipment and quality control systems.

 Material Expertise

Deep knowledge of bronze casting alloys and their electrical/mechanical properties enables us to recommend optimal
